Honda 2″ (inch) Water Pump

The Dayliff Range of portable petrol generators are dependable, quality products specially designed for mains standby and remote site power supply applications. Particular features include:

• Reliable and economical air cooled OHV petrol engines equipped with large size exhausts and air cleaners for low noise operation.
• High efficiency square core alternators providing increased power output and enabling operation of sensitive electronic equipment.
• DC output for charging.
• Strong tubular frame for protection and ease of handling(not DG950P and DG11000PS).
• Integrated control panel with voltmeter for operational convenience.
• Fuseless type over current protection.
• Oil alert system to stop engine in the event of low oil level(not DG950P).

High capacity fuel tank for extended operation (not DG950P) Dayliff generators are of compact design and their advanced features make them suitable for all small scale power supply applications.

Generator Information
Model	DG5000P
Output - Rated(kVA)	4
Output - Max(kVA)	4,5
Engine Model	LT390,4T
Engine Capacity(cc)	389
Engine Max Power(HP)	13
Speed	3000rpm
Fuel Tank Capacity(L)	25
Operating Period	5Hrs
Starter	Electric
Derating	Given outputs are sea level ratings. Sets should be derated at 1% for every 100m higher than 100m above sea level, and 2% for every 5° C temperature increase above 20°C
Noise Level	Acoustic Set with AMF, noise level: 70dBA@7m
Dimensions & Weights
Dimension(mm) L	650
Model	DG5000P
Dimension(mm) H	550
W (mm)	512
Weight (kg)	74.5
Electrical Data
Alternator	Brushless, self exciting, 2 pole
Power Output	50Hz, 240V, single phase
Voltage Regulator	AVR
Power Factor	1
